SmartRelay 3 system
10.8 Near-field option
(Manual)
Descrip-
Time
tion
Time
between
last data
t bit and de-
CLS+
activation
of the CLS
signal
Data format (OMRON Isgus)
Each message below consists of a sequence of letters ("characters").
Each "character" is represented by a sequence of 5 bits (BCD code +
parity):
Bit 1 (LSB) Bit 2
Data structure of a message:
S BBBB M AAAA E L
Meaning:
S
B
M
A
E
L
A reduced reader range is required in some situations. The near-field option
reduces the reader range for transponders. This reduces the influence of
possible interferences and prevents the transponder from overriding.
Min. Typ.
8 12
Bit 3 Bit 4 (MSB)
Start character (hex B)
User ID number (0 to 9,999)
5th digit of the user ID number
Facility code (0 to 9,999)
End character (hex F)
Longitudinal parity check character
(over all transmitted characters
XOR[S...E])
10. SREL3 ADV in LSM
131 / 189
Max. Unit
20 ms
Bit 5 (odd parity
bit over bits 1 to 4)
