SmartRelay 3 system (Manual)
An authorised identification device is activated on the reader. The relay

contact of the SmartRelay closes.
The button is actuated. The relay contact of the SmartRelay closes.

A remote opening of the SmartRelay is performed.

You can use the following cable types under the following conditions. (For
detailed wiring information, see
Number
1
2
3
Information on cabling [
Framework conditions Cable type
Cable length power
supply unit to controller
≤ 15 m (15 m outward
and 15 m return)
Cable length controller
to reader (or controller
to button) ≤ 15 m (15 m
outward and 15 m re-
turn)
Connection directly

to the power supply
unit
Cable length power

supply unit-locking
device-controller ≤
50 m (50 m
outward and 50 m
return)
Locking device

suitable for 9 V to
DC
maximum power
supply, maximum
power of the locking
device ≤ 4.5 W
8. Setting up
95 / 189
178]
).
}
F-YAY 2x2x0.6
CAT5, shielded
F-YAY 2x2x0.6
