SmartRelay 3 system
8.4.5.5 Wiring in lift
(Manual)
Descrip-
Time
tion
Time
between
last data
t bit and de-
CLS+
activation
of the CLS
signal
Data format (OMRON Isgus)
Each message below consists of a sequence of letters ("characters").
Each "character" is represented by a sequence of 5 bits (BCD code +
parity):
Bit 1 (LSB) Bit 2
Data structure of a message:
S BBBB M AAAA E L
Meaning:
S
B
M
A
E
L
Lift cabs are connected to the external system via trailing cables. The
number of available lines is limited by the trailing cable type. You can save
on free lines if you decide on a configuration with few lines.
Min. Typ.
8 12
Bit 3 Bit 4 (MSB)
Start character (hex B)
User ID number (0 to 9,999)
5th digit of the user ID number
Facility code (0 to 9,999)
End character (hex F)
Longitudinal parity check character
(over all transmitted characters
XOR[S...E])
8. Setting up
84 / 189
Max. Unit
20 ms
Bit 5 (odd parity
bit over bits 1 to 4)
