CMOS Jumper

When clearing CMOS (JP8), use the following procedure.
Turn off and unplug the system and any external op-
1.
tions.
WARNING: The system power must be
off before changing a jumper setting.
Remove the system unit cover (see Chapter 5).
2.
Locate the jumper(s) on the system board (see the fig-
3.
ure under "Jumper Locations" earlier in this chapter).
You might have to remove installed expansion boards
to access the jumper (see expansion board removal pro-
cedures in Chapter 4).
Install a jumper on jumper JP8.
4.
Power on the system for 5 seconds. The monitor will be
5.
blank.
Power off the system.
6.
Remove the jumper from jumper JP8.
7.
Replace the system unit cover (see Chapter 5).
8.
Run Setup (see Chapter 2).
9.
Setting System Board Jumpers 7-7
