DATA STORAGE DEVICES

Storage Device Support

Lock the processor in place by swinging the socket
7.
lever down towards the socket until it locks in place.
Set the processor speed and voltage jumpers (see
8.
Chapter 7, "Setting System Board Jumpers").
Replace any expansion boards that you removed (see
9.
"Board Installation" earlier in this chapter) and recon-
nect any cables.
Turn the system upright and replace the system unit
10.
cover (see Chapter 5).
The following sections describe:
n
the storage devices supported by your system
n
the device slots in your computer
n
device preparation, such as switch and jumper settings
n
device cables and cable connector locations
n
procedures for installing storage devices.
The system board in your computer supports the following
peripheral storage devices:
n
up to two diskette drives, including the standard
1.44-MB diskette drive
n
up to four devices such as hard disks and a CD-ROM
reader.
Other storage devices might require the installation of a
compatible controller board. See your hardware dealer for
the storage devices available for your system.

Adding Options 6-37
