Setting Onboard VGA

If you add a graphics board to your system, you must disable the onboard VGA
by changing the jumper setting on block JVGA1 (see the following table).
JVGA1
1-2
2-3

Clearing CMOS

If you need to manually reset your CMOS settings to their factory state, change
the jumper setting on block JBAT1 after the system has been unplugged. The
following table lists the jumper settings, and the function of each setting. Move
the jumper back to pins 1-2 (to keep future CMOS changes) after waiting
approximately five seconds.
JBAT1
1-2
2-3

Setting the Power On Mode

Your system can be jumpered to start up in two ways:
T
when the power button is pressed, or
T
when the power cable is connected ("Immediate Boot Up").
To change the way your system starts up, change the jumper setting on block
JP1. The following table lists the jumper settings, and the function of each
setting.
Note:
Utility, it overrides the JP1 jumper setting.
JP1
1-2
none

Onboard VGA Jumper Settings

Function
Enables onboard VGA.
Disables onboard VGA.

CMOS Clear Jumper Settings

Function
Keeps CMOS changes.
Clears CMOS changes.
If a Power On mode is set in the CMOS Setup

Power On Mode Jumper Settings

Function
Boot up when power button is pressed.
Immediate boot up when power cable is connected.
System Configuration 2-5
