NEC POWERMATE VP Manual page 174

n
Connect an unused connector on the PCI/IDE cable
and on the power cable into the device.
Take care to prevent bending drive connector pins.
Be sure to align the PCI/IDE cable connector as
shown in the figure.
Push the device bracket up against the chassis and se-
2.
cure in place with the five previously removed screws.
Install the front panel to the chassis with the four pre-
3.
viously removed screws (two to a side).
If you installed a 1.2-MB diskette drive, remove the
4.
protective cardboard insert from the drive.
Replace the system unit cover (see Chapter 5).
5.
Be sure that you do not pinch any cables or wires when
you install the cover.
Connecting the PCI/IDE device cables
Adding Options 6-59
