System Power Cables

Diskette Drive Signal Cable

6-42 Adding Options
System power cables vary in length and provide connector
sizes to accommodate a variety of supported storage
configurations. Power cable connectors are keyed to fit
only in the correct position.
The diskette drive signal cable that comes attached to the
system board only connects the standard 1.44-MB diskette
drive. An optional diskette drive cable (shown in the fol-
lowing figure) is required if attaching a second diskette
drive.
The NEC spare part number for the optional diskette drive
cable that supports two devices is 158-050561-000.
Power cable connectors
