FAN CONNECTOR
Fan connector pin assignments are given in Table Appendix A-9. The connector plugs into
one of the power supply cable connectors.
Table Appendix A-9 Fan Connector Pin Assignments
Pin
1
2
3
DISKETTE DRIVE INTERFACE PIN ASSIGNMENTS
Table Appendix A-10 provides the pin assignments for the diskette drive interface.
Table Appendix A-10 Diskette Drive Connector Pin Assignments
Ground Pin
Signal Pin
1
2
3
4
5*
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
*Pin 5 is reserved for connector polarization.
Signal
Ground
+12V (fused)
Ground
I/O
O
O
O
O
O
O
O
O
I
I
I
O
I
Connector Pin Assignments
Signal Name
FDHDIN
Not used
FDEDIN
INDEX
MOTEN1
DS2
DS1
MOTEN2
DIR
STEP
WRT DATA
WRT EN GATE
TRK0
WRT PROT
READ DATA
HS SEL
DSKT CHG
A-9
