C
ONFIGURING THE
CLI – This example enables Spanning Tree Protocol, sets the mode to
MST, and then configures the STA and MSTP parameters.
Console(config)#spanning-tree
Console(config)#spanning-tree mode mstp
Console(config)#spanning-tree priority 4096
Console(config)#spanning-tree hello-time 5
Console(config)#spanning-tree max-age 38
Console(config)#spanning-tree forward-time 20
Console(config)#spanning-tree pathcost method long
Console(config)#spanning-tree transmission-limit 4
Console(config)#spanning-tree mst-configuration
Console(config-mstp)#revision 1
Console(config-mstp)#name R&D
Console(config-mstp)#max-hops 30
Console(config-mstp)#

Displaying Interface Settings

The STA Port Information and STA Trunk Information pages display the
current status of ports and trunks in the Spanning Tree.
Field Attributes
• Port – Ports 1 - 8.
• Spanning Tree – Shows if STA has been enabled on this interface.
• STA Status – Displays current state of this port within the Spanning
Tree:
-
-
-
The rules defining port status are:
-
3-168
S
WITCH
Discarding - Port receives STA configuration messages, but does
not forward packets.
Learning - Port has transmitted configuration messages for an
interval set by the Forward Delay parameter without receiving
contradictory information. Port address table is cleared, and the
port begins learning addresses.
Forwarding - Port forwards packets, and continues learning
addresses.
A port on a network segment with no other STA compliant
bridging device is always forwarding.
