C
ONFIGURING THE
CLI – This command displays global STA settings, followed by settings for

each port.

Console#show spanning-tree
Spanning-tree information
---------------------------------------------------------------
Spanning tree mode:
Spanning tree enable/disable:
Instance:
Vlans configuration:
Priority:
Bridge Hello Time (sec.):
Bridge Max Age (sec.):
Bridge Forward Delay (sec.):
Root Hello Time (sec.):
Root Max Age (sec.):
Root Forward Delay (sec.):
Max hops:
Remaining hops:
Designated Root
Current root port:
Current root cost
Number of topology changes:
Last topology changes time (sec.): 13380
Transmission limit:
Path Cost Method:
---------------------------------------------------------------
Eth 1/ 1 information
---------------------------------------------------------------
Admin status:
Role:
State:
External admin path cost: 1000
Internal admin cost:
External oper path cost:
Internal oper path cost:
Priority:
Designated cost:
Designated port:
Designated root:
Designated bridge:
Fast forwarding:
Forward transitions:
Admin edge port:
Oper edge port:
Admin Link type:
Oper Link type:
Spanning Tree Status:
.
.
.
.
Note: The current root port and current root cost display as zero when
this device is not connected to the network.
3-162
S
WITCH
MSTP
enable
0
1-4094
32768
2
20
15
2
20
15
20
20
32768.0.0000ABCD0000
1
200000
1
3
long
enabled
disable
discarding
1000
1000
1000
128
300000
128.1
32768.0000E8AAAA00
32768.0030F1D473A0
disabled
0
disabled
disabled
auto
point-to-point
enabled
4-226
