C
ONFIGURING THE
CLI – The following example configures LACP parameters for ports 1-6.
Ports 1-4 are used as active members of the LAG, ports 5 and 6 are set to

backup mode.

Console(config)#interface ethernet 1/1
Console(config-if)#lacp actor system-priority 3
Console(config-if)#lacp actor admin-key 120
Console(config-if)#lacp actor port-priority 128
Console(config-if)#exit
. .
.
Console(config)#interface ethernet 1/6
Console(config-if)#lacp actor system-priority 3
Console(config-if)#lacp actor admin-key 120
Console(config-if)#lacp actor port-priority 512
Console(config-if)#end
Console#show lacp sysid
Channel Group
-------------------------------------------------------------------
. .
.
Console#show lacp 1 internal
Port channel: 1
-------------------------------------------------------------------
Oper Key:
Admin Key: 0
Eth 1/ 1
-------------------------------------------------------------------
LACPDUs Internal:
LACP System Priority: 3
LACP Port Priority:
Admin Key:
Oper Key:
Admin State: defaulted, aggregation, long timeout, LACP-activity
Oper State:
. .
.
3-134
S
WITCH
System Priority
1
2
3
120
30 sec
128
120
120
distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
System MAC Address
3 00-00-E9-31-31-31
32768 00-00-E9-31-31-31
32768 00-00-E9-31-31-31
4-170
4-190
4-191
4-193
4-194
4-194
