SMC Networks 8708L2 - annexe 1 Management Manual page 81

CLI – To download new firmware form a TFTP server, enter the IP
address of the TFTP server, select "config" as the file type, then enter the
source and destination file names. When the file has finished downloading,
set the new file to start up the system, and then restart the switch.
To start the new firmware, enter the "reload" command or reboot the
system.
Console#copy tftp file
TFTP server ip address: 10.1.0.19
Choose file type:
1. config: 2. opcode: <1-2>: 2
Source file name: V3002.bix
Destination file name: V3002
\Write to FLASH Programming.
-Write to FLASH finish.
Success.
Console#config
Console(config)#boot system opcode:V3002
Console(config)#exit
Console#reload
