C
ONFIGURING THE
Web – Click Port, LACP, Port Internal Information. Select a port channel
to display the corresponding information.
CLI – The following example displays the LACP configuration settings
and operational state for the local side of port channel 1.
Console#show lacp 1 internal
Port channel: 1
-------------------------------------------------------------------
Oper Key:
Admin Key: 0
Eth 1/ 2
-------------------------------------------------------------------
LACPDUs Internal:
LACP System Priority: 32768
LACP Port Priority:
Admin Key:
Oper Key:
Admin State: defaulted, aggregation, long timeout, LACP-activity
Oper State:
. .
.
3-138
S
WITCH

Figure 3-57 LACP - Port Internal Information

3
30 sec
32768
3
3
distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
4-194
