C
ONFIGURING THE
Web – Click Port, Mirror Port Configuration. Specify the source port, the
traffic type to be mirrored, and the monitor port, then click Add.
CLI – Use the interface command to select the monitor port, then use the
port monitor command to specify the source port. Note that default
mirroring under the CLI is for both received and transmitted packets.
Console(config)#interface ethernet 1/7
Console(config-if)#port monitor ethernet 1/8
Console(config-if)#
3-144
S
WITCH

Figure 3-60 Mirror Port Configuration
