Chapter 1 — Using the Printer
Media Compartment and Print Mechanism
4
Media Compartment
Label taken
sensor
Thermal
printhead
Print Mechanism
Ink position lever
Edge guide
Media supply post
Ribbon supply shaft
Ribbon rewind shaft
Printhead
balance boxes
Tear bar
EasyCoder PD42 Printer User's Guide
Ribbon
rod
Printhead
lever
Media
feed rods
