Chapter 2—Installation
Print Mechanism
The print mechanism features a high-performance thermal printhead
with quick-mount fi ttings to facilitate replacement.
Thermal
printhead
Tear bar
(tear upwards)
Pressure arm
Tear bar
(tear downwards
and peel-off))
Platen roller
12
Intermec EasyCoder PF4i Compact Industrial—User's Guide (Fingerprint)
Ribbon rewind hub
Label stop sensor
position adjustment
(bottom sensor hidden)
Ribbon supply hub
Edge guide
Printhead lift lever
