Chapter 2 — Installation
Print Mechanism
10
The print mechanism features a high-performance thermal
printhead with quick-mount fittings to facilitate replacement.
Ribbon
break
shaft
Thermal
printhead
Pressure
arm
Finisher
interface
Tear bar
(tear upwards)
Platen
roller
Tear bar
(tear downwards
and peel-off )
EasyCoder PM4i Printer User's Guide (Fingerprint Version)
Ribbon
rewind
Ribbon
hub
supply
hub
Label stop sensor
position adjustment
Printhead
lift lever
Edge
guide
