Chapter 2 — Installation

Print Mechanism

Print
mechanism
Long side door
12 EasyCoder PF2i Bar Code Label Printer User's Guide (Fingerprint Version)
The print mechanism features a high-performance 8 dot/mm
(203.2 dots/inch) thermal printhead with quick-mount fittings
to facilitate replacement. Refer to
on page 41 and "Options" on page 89
thermal transfer mechanism, which is partly integrated with the
print mechanism.
"Thermal Transfer Printing"
for illustrations of the
Media supply
roll post with
edge guide
Optional integral
liner takeup with
guide shaft
