Online Insertion and Removal with a CE Network Module
Save the running configuration of the content engine using the following command from the
Step 2
CE-netmodule prompt:
CE-netmodule# copy running-config tftp tftp-server-address filename
Exit the CE network module console access session by pressing Control-Shift-6, followed by x.
Step 3
On the router, clear the CE console access session using the following command:
Step 4
Router# service-module content-engine slot / unit session clear
Step 5 Perform a graceful halt of the CE network module disk drive by using the following command:
Router# copy tftp running-config tftp-server-addresss filename
Shut down the content engine interface:
Step 6
Router (config)# interface content-engine slot/unit
Router (config-if)# shutdown
Router (config-if)# exit
Unplug all network interface cables from the CE network module.
Step 7
Loosen the two captive screws holding the CE network module in the chassis slot.
Step 8
Step 9 Slide the CE network module out of the slot.
Step 10 Align the replacement CE network module with the guides in the chassis slot, and slide it gently into the
slot.
Note
Step 11 Push the module into place until you feel its edge connector mate securely with the connector on the
backplane.
Reconnect the network interface cables previously removed in
Step 12
Step 13 Check that the network module LEDs are on and that the power and enable LEDs on the front panel also
are on. This inspection ensures that connections are secure and that the new unit is operational.
Step 14 Initiate a CE network module console access session with the following command:
Router# service-module content-engine slot / unit session
Trying 10.10.10.1, 2129 ... Open
CE-netmodule con now available
Press RETURN to get started!
CE-netmodule> enable
CE-netmodule#
Step 15 Restore the content engine's running configuration by using the following command from the
CE-netmodule prompt:
CE-netmodule# copy tftp running-config tftp-server-address filename
Step 16 Exit the CE network module console access session by pressing Control-Shift-6, followed by x.
Cisco Network Modules Hardware Installation Guide
19-6
Chapter 19
If the router is not fully configured with network modules, make sure that blank panels fill
the unoccupied chassis slots to provide proper airflow.
Connecting Content Engine Network Modules for Caching and Content Delivery
Step 7.
