2.4 QSPI Flash

The board is equipped with two 256MBit Quad-SPI FLASH chips to form an
8-bit bandwidth data bus, the FLASH model is W25Q256FVEI, which uses the 3.3V
CMOS voltage standard. Due to the non-volatile nature of QSPI FLASH, it can be
used as a boot device for the system to store the boot image of the system.
These images mainly include FPGA bit files, ARM application code, and other user
data files. The specific models and related parameters of QSPI FLASH are shown
in Table 2-4-1.
Bit Number
U13, U14
Table 2-4-1: QSPI FLASH specification and parameters
