AX7Z035B User Manual
HDMI_D6
HDMI_D7
HDMI_D8
HDMI_D9
HDMI_D10
HDMI_D11
HDMI_D12
HDMI_D13
HDMI_D14
HDMI_D15
HDMI_D16
HDMI_D17
HDMI_D18
HDMI_D19
HDMI_D20
HDMI_D21
HDMI_D22
HDMI_D23
HDMI_INT
HDMI_SCL
HDMI _SDA

3.6 HDMI Input Interface

The HDMI input interface uses Silion Image's SIL9011/SIL9013 HDMI decoder
chip, which supports up to 1080P@60Hz input and supports data output in different
formats.
Among them, the IIC configuration interface of SIL9011/SIL9013 is also
connected with the IO of BANK13 of FPGA. ZYNQ initializes and controls SIL9013 by
programming I2C bus. The hardware connection of HDMI input interface is shown in
Figure 3-6-1.
www.alinx.com
B35_L8_N
B35_L12_P
B35_L12_N
B35_L9_N
B35_L1_N
B35_L1_P
B35_L17_N
B35_L17_P
B35_L20_N
B35_L20_P
B35_L10_N
B35_L10_P
B35_L13_N
B35_L13_P
B35_L16_N
B35_L16_P
B35_L15_P
B35_L15_N
B35_L21_P
B35_L18_P
B35_L18_N
J13 HDMI video signal data 6
J14 HDMI video signal data 7
H14 HDMI video signal data 8
J15 HDMI video signal data 9
E12 HDMI video signal data 10
F12 HDMI video signal data 11
B15 HDMI video signal data 12
B16 HDMI video signal data 13
B14 HDMI video signal data 14
C14 HDMI video signal data 15
G15 HDMI video signal data 16
G16 HDMI video signal data 17
D14 HDMI video signal data 18
D15 HDMI video signal data 19
D16 HDMI video signal data 20
E16 HDMI video signal data 21
C17 HDMI video signal data 22
C16 HDMI video signal data 23
A15 HDMI Interrupt signal
B17 HDMI IIC control clock
A17 HDMI IIC control data
44 / 58
