AX7Z035B User Manual
9013_D[10]
9013_D[11]
9013_D[12]
9013_D[13]
9013_D[14]
9013_D[15]
9013_D[16]
9013_D[17]
9013_D[18]
9013_D[19]
9013_D[20]
9013_D[21]
9013_D[22]
9013_D[23]
9013_SCL
9013 _SDA

3.7 SFP Interface

The AX7Z035B carrier board has four SFP interfaces. Users can purchase SFP
optical modules (1.25G, 2.5G, 10G optical modules on the market) and insert them
into these four interfaces for optical data communication. The four SFP interfaces
are connected to the two RX/TX of the GNK transceiver of ZYNQ BANK111. The TX
signal and the RX signal are connected to the ZYNQ and the optical module through
the DC blocking capacitor in differential signal mode. The TX and RX data rates are
up to 10Gb/s per channel. The reference clock for the GTX transceiver of BANK111 is
provided by the 125M differential clock of AC7Z035B FPGA core board.
The schematic diagram of FPGA and fiber optic design is shown in Figure 3-7-1:
www.alinx.com
B13_L8_P
B13_L8_N
B13_L10_N
B13_L10_P
B13_L15_N
B13_L15_P
B13_L23_N
B13_L23_P
B13_L22_P
B13_L22_N
B13_L17_N
B13_L17_P
B13_L19_N
B13_L19_P
B13_L3_N
B13_L3_P
AE23 9013 video signal data 10
AF23 9013 video signal data 11
AA23 9013 video signal data 12
AA22 9013 video signal data 13
AF20 9013 video signal data 14
AF19 9013 video signal data 15
W19 9013 video signal data 16
W18 9013 video signal data 17
AA19 9013 video signal data 18
AB19 9013 video signal data 19
AD19 9013 video signal data 20
AD18 9013 video signal data 21
Y20 9013 video signal data 22
W20 9013 video signal data 23
AE26 9013 IIC control clock
AE25 9013 control data
