I2C configuration interface are connected to the PL BANK35 IO of the ZYNQ7000.
The ZYNQ7000 system initializes and controls the ADV7511 through the I2C pin. The
hardware connection diagram of ADV7511 chip and ZYNQ7000 is shown in Figure 3-
5-1.
Figure 3-5-1: Schematic diagram of HDMI output interface design
ZYNQ pin assignment：
Signal Name
HDMI_CLK
HDMI_HSYNC
HDMI_VSYNC
HDMI_DE
HDMI_D0
HDMI_D1
HDMI_D2
HDMI_D3
HDMI_D4
HDMI_D5
43 / 58
ZYNQ Pin Name
B35_L9_P
B35_L3_N
B35_L3_P
B35_L7_N
B35_L7_P
B35_L4_P
B35_L4_N
B35_L5_N
B35_L5_P
B35_L8_P
AX7Z035B User Manual
ZYNQ Pin
Number
K15 HDMI Video signal clock
HDMI Video signal line
F10
HDMI Video signal column
G10
H12 HDMI video signal is valid
H13 HDMI video signal data 0
E11 HDMI video signal data 1
D11 HDMI video signal data 2
G11 HDMI video signal data 3
G12 HDMI video signal data 4
K13 HDMI video signal data 5
Description
synchronization
synchronization
