U1
ZYNQ
ZYNQ pin assignment：
Signal Name
9013_nRESET
9013_CLK
9013_HS
9013_VS
9013_DE
9013_D[0]
9013_D[1]
9013_D[2]
9013_D[3]
9013_D[4]
9013_D[5]
9013_D[6]
9013_D[7]
9013_D[8]
9013_D[9]
45 / 58
9013_CLK
9013_DE
9013_HS
9013_VS
9013_D[23:16]
9013_D[15:8]
9013_D[7:0]
9013_SCL
9013_SDA
9013_nRESET
Figure 3-6-1: HDMI input schematic diagram
ZYNQ Pin Name
B13_L24_N
B13_L11_P
B13_L5_P
B13_L5_N
B13_L4_N
B13_L4_P
B13_L11_N
B13_L12_N
B13_L12_P
B13_L2_P
B13_L2_N
B13_L6_N
B13_L6_P
B13_L1_N
B13_L1_P
AX7Z035B User Manual
U9
QDCK
DE
HSYNC
VSYNC
QE[23:16]
QE[15:8]
QE[7:0]
CSCL
CSDA
RESET#
ZYNQ Pin
Number
AA18
AD23 9013 video signal clock
9013 video signal line
AF24
9013 video signal column
AF25
AD26 9013 video signal valid
AD25 9013 video signal data 0
AD24 9013 video signal data 1
AC24 9013 video signal data 2
AC23 9013 video signal data 3
AB26 9013 video signal data 4
AC26 9013 video signal data 5
AB24 9013 video signal data 6
AA24 9013 video signal data 7
AB25 9013 video signal data 8
AA25 9013 video signal data 9
J7
TDMS
Description
9013 Reset Signal
synchronization
synchronization
