Figure 3-7-1: Schematic diagram of fiber optic design
Pin assignment of 4 SFP interfaces:
Signal Name
ZYNQ Pin Name
SFP1_TX_P
BANK111_TX0_P
SFP1_TX_N
BANK111_TX0_N
SFP1_RX_P
BANK111_RX0_P
SFP1_RX_N
BANK111_RX0_N
SFP2_TX_P
BANK111_TX1_P
SFP2_TX_N
BANK111_TX1_N
SFP2_RX_P
BANK111_RX1_P
SFP2_RX_N
BANK111_RX1_N
SFP3_TX_P
BANK111_TX2_P
47 / 58
AX7Z035B User Manual
ZYNQ Pin
Number
Optical module 1 transmit data
AF8
Optical module 1 transmit data
AF7
Optical module 1 receive data
AD8
Optical module 1 receive data
AD7
Optical module 2 transmit data
AF4
Optical module 2 transmit data
AF3
Optical module 2 receive data
AE6
Optical module 2 receive data
AE5
AE2
Optical module 3 transmit data
Description
positive
negative
positive
negative
positive
negative
positive
negative
www.alinx.com
