3.9 SD Card Slot

The AX7Z035B FPGA board contains a Micro SD card interface to provide user
access to the SD card memory, the BOOT program for storing the ZYNQ chip, the
Linux operating system kernel, the file system and other user data files.
The SDIO signal is connected to the IO signal of the PS BANK501 of ZYNQ. Since
the VCCMIO of the BANK is set to 1.8V, but the data level of the SD card is 3.3V, so
here we use the TXS02612 level converter to realize the connection. The schematic
of the Zynq7000 PS and SD card connector is shown in Figure 3-9-1:
