3.4 USB2.0 Host Interface

There are 4 USB2.0 HOST interfaces on the AX7Z035B FPGA development board.
The USB2.0 transceiver uses a 1.8V, high-speed USB3320C-EZK chip that supports
the ULPI standard interface, and then expands the 4-way USB HOST interfaces
through a USB HUB chip USB2514. ZYNQ's USB bus interface is connected to the
USB3320C-EZK transceiver for data communication in the high-speed USB2.0 Host
mode. The USB3320C's USB data and control signals are connected to the IO port of
PS BANK501 of the ZYNQ chip. The USB interface's differential signal (DP/DM) is
connected to the USB2514 chip to extend four USB interfaces. Two 24MHz crystals
provide clocks for USB3320C and USB2514 chips, respectively.
Four USB interfaces are flat-type USB interfaces (USB Type A), which allows users
to connect different USB Slave peripherals (such as USB mouse and USB keyboard)
at the same time. Each USB interface provides +5V power.
The schematic diagram of the connection among ZYNQ processor, USB3320C-
EZK chip and USB2514 chip is shown as Figure 3-4-1:
41 / 58
