BANK12 and BANK13 is generated through two SPX3819M5-3-3 channels. Users can
replace the LDO chip to make the IO input and output of these two BANKs meet
other voltage standards.
The functions of each power distribution are shown in the following table:
Power Supply
+1.0V
+1.8V
+3.3V
+1.5V
VCCIO12
VCCIO13
VREF, VTT
（+0.75V）
MGTAVCC(+1.0V)
MGTAVTT(+1.2V)
MGTVCCAUX
（+1.8V）
Because the power supply of the ZYNQ FPGA has the power-on sequence
requirements, in the circuit design, we have designed according to the power
requirements of the chip. The power-on sequence is +1.0V->+1.8V-> (+1.5 V, +3.3V,
VCCIO12, VCCIO13) circuit design to ensure the normal operation of the chip.
