Function - Icom ID-52A PLUS Advanced Manual

12
SET MODE

Function

Power Save
[MENU] > SET > Function > Power Save
Sets the Power Save function to reduce the current
drain and conserve battery power� When the Power
Save function is activated, the call sign or the
beginning of the signal may not be received correctly�
• OFF: Turns OFF the function�
• Auto (Short): Sets the Power saving time to
"Short�"
15 ms
Standby
Reception→
Disabled
75 ms
No signal is received
for 5 seconds.
• Auto (Middle): Sets the Power saving time to
"Middle�"
15 ms
Standby
Reception→
Disabled
75 ms
↑
60 s
No signal is received
for 5 seconds.
• Auto (Long): Sets the Power saving time to
"Long�"
15 ms
Standby
Reception→
Disabled
75 ms
↑
60 s
No signal is received
for 5 seconds.
NOTE: The Power Save function is disabled when:
• Using an external DC power source�
• Scanning�
• Using the DV Gateway function in the Access Point
mode�
• Using the VOX function�
Monitor
[MENU] > SET > Function > Monitor
Selects an option for the [SQL] Monitor function�
(Basic manual Section 3)
• Push: Hold down [SQL] to monitor the frequency�
Release to stop monitoring�
• Hold: Push [SQL] momentarily to monitor the
frequency and push momentarily again to
cancel it�
(Default: Auto (Short))
15 ms
150 ms
15 ms
300 ms
(Default: Push)
Dial Speed-UP
[MENU] > SET > Function > Dial Speed-UP
Turns the Dial Speed Acceleration ON or OFF�
The acceleration automatically increases the tuning
speed when you rapidly rotate [DIAL]�
• OFF: Turns OFF the function�
• ON: Turns ON the function�
Auto Repeater
[MENU] > SET > Function > Auto Repeater
The Auto repeater function automatically turns the
duplex operation and tone encoder ON or OFF�
L This item is displayed in only the USA version�
• OFF:
• ON (DUP):
• ON (DUP, TONE): Turns ON the duplex settings
Remote MIC Key
[MENU] > SET > Function > Remote MIC Key
The function assignments for the [A], [B], [], and []
keys on the optional HM-243LS or HM-75LS remote
control speaker microphone can be changed�
See pages 12-19 and 12-20 for the assignable key
functions�
• During RX/Standby: The assigned key function is
• During TX:
TIP: Volume level adjustment while monitoring
• When "VOL UP"/"VOL DOWN" are assigned, push
these keys to adjust the volume level�
• When "VOL UP"/"VOL DOWN" are not assigned, but
"UP"/"DOWN" are assigned, push these keys to adjust
the volume level�
• When "VOL UP"/"VOL DOWN"/"UP"/"DOWN" are not
assigned, push []/[] to adjust the volume level, if
"Monitor (Push)" or "Monitor (Hold)" is not assigned to
[]/[]�
12-18
(Default: ON)
(Default: ON (DUP))
Turns OFF the function�
Turns ON the duplex settings
only�
and the tone encoder function�
enabled while receiving or in
the standby mode�
(Default: [A]: BAND
[B]: VFO/MR
[]: UP
[]: DOWN)
The assigned key function is
enabled while transmitting�
(Default: [A]: T-CALL
[B]: ---
[]: ---
[]: ---)
