14
SHARE PICTURES FUNCTION

Preparing a TX picture

There are 2 ways to prepare a TX picture�
• Transfer from a mobile device using the Picture Utility software, through Bluetooth�
• Save on a microSD card using the PC or mobile device�
DTransfer from the mobile device
through Bluetooth
1� Insert a microSD card into the transceiver's slot,
and then turn ON the transceiver�
2� In the mobile device, open the Picture Utility
software�
L When using an Android device for the first time, pair
the transceiver with your device� (p� 17-7)
3� Open the Transfer Settings screen�
4� Select "Using Bluetooth," and then set "Transfer
Devices" to your transceiver�
L When using an iOS device for the first time, pair the
transceiver with your device� (p� 17-9)
L See the ST-4001A or ST-4001I instruction manual
for details� They can be downloaded from the Icom
website�
5� Open a picture to transfer using the Picture Utility
software�
6� Touch the Transfer ( ) button�
• Starts transferring, and the transferred picture is
saved on the microSD card�
L The file name is automatically set in the following
format: YYYYMMDD_hhmmss (YYYY: Year, MM:
month, DD: day, hh: hour, mm: minute, ss: second)�
NOTE: If you cannot transfer the picture, check the
following:
On the transceiver
• The transceiver is turned ON�
• The Bluetooth function is ON�
• The transceiver's firmware is the latest version�
• A microSD card is inserted into the transceiver�
• The transceiver is in a normal operating mode�
L The transceiver cannot receive the picture in special
modes, such as the firmware update mode, clone
mode, setting save mode, and import or export mode�
On the device
• The Bluetooth function is ON�
• "Transfer Devices" is set to your transceiver�
DSave on the microSD card using the
PC or mobile device
1� Turn OFF the transceiver, then remove the
microSD card from the transceiver�
2� Insert it into the microSD card drive or a memory
card reader* on your PC or mobile device�
* User supplied�
3� Copy a picture file, and paste it in the "Picture"
folder ("ID-52" > "Picture") on the card�
4� Remove the card from your device, and insert it
into the transceiver's slot�
NOTE: Before you remove the SD card, be sure to
electrically unmount it� Otherwise, the data may be
corrupted or deleted�
TIP:
• When "USB Connect" is set to "SD Card Mode," and the
transceiver is connected to the PC through a USB data
cable, you can directly access the microSD card that is
set in the transceiver from the PC�
([MENU] > SET > Function > USB Connect)
• You can save a received picture in the "Picture" folder
on the SD card� (p� 14-7)
14-4
