Icom ID-52A PLUS Advanced Manual page 260

17
OPTIONS
Connecting an Android™ device to the transceiver through Bluetooth
DConnection
This section describes how to connect an Android
device to the transceiver, using the RS-MS1A
application
Before connecting, pair the transceiver with the
Android device (p 17-7)
L When using the ST-4001A application, the transceiver
and Android device are automatically connected while
transferring a picture
L When using the RS-MS3A application, the transceiver
and Android device are automatically connected after
select "Bluetooth Connection Device" in the RS-MS3A
"Connection," and then "Start"
Step 1. Preparing for the connection (Transceiver)
[MENU] > SET > Function > CI-V > CI-V Transceive
Set "CI-V Transceive" to ON to control the transceiver
and the RS-MS1A with CI-V commands
Step 2. Starting the RS-MS1A
Touch the RS-MS1A to start
L See page 17-6 for details on downloading the RS-MS1A
Step 3. Connecting to the transceiver
Touch the transceiver's Bluetooth unit name displayed
on the RS-MS1A
• Starts to connect
L When your call sign has not been entered in the
transceiver, you should enter it before you connect
L After the connection has been made, the transceiver
displays " MMM Connected," and the Bluetooth icon is
displayed
L On the PAIRING/CONNECT screen, "
Device name
Displayed while connecting
(Android device)
(Android device)
Displayed
" is displayed
®
TIP: To connect to the Android device from the
transceiver
When the RS-MS1A is started on the Android device,
you can connect to the device from the transceiver
[MENU] > SET > Bluetooth Set > Pairing/Connect
1 Push [MENU]
2 Select "Bluetooth Set" in the SET menu
3 Select "Pairing/Connect."
4 Select the Android device name displayed in the
pairing list
5 Select "YES"
• Displays " MMM
MMM
( " " is the Bluetooth name of the Android
device)
L On the PAIRING/CONNECT screen, "
displayed on the data device icon
NOTE: If you cannot connect, check that the same
CI-V address is set in the transceiver and the
RS-MS1A
You can see the CI-V setting as described below:
Transceiver
"CI-V Address" in the MENU screen
([MENU] > SET > Function > CI-V > CI-V Address)
(Default: B4)
RS-MS1A:
"Application Settings" → "CI-V settings"
(Default: Transceiver[B4])
17-8
Connecting"
" is
