Icom ID-52A PLUS Advanced Manual page 122

6
GPS OPERATION (ADVANCED)
GPS items
Power
[MENU] > GPS > GPS TX Mode > D-PRS >
TX Format > Item > Power
Selects the TX power level of Item, to transmit along
with the position data�
L This item is displayed when "Data Extension" is set to
"Power/Height/Gain/Directivity�"
• Select 0, 1, 4, 9, 16, 25, 36, 49, 64, or 81 W�
Height
[MENU] > GPS > GPS TX Mode > D-PRS >
TX Format > Item > Height
Selects the height of the Item's antenna to transmit
along with the position data�
L This item is displayed when "Data Extension" is set to
"Power/Height/Gain/Directivity�"
• Select 10, 20, 40, 80, 160, 320, 640, 1280, 2560, or
5120 feet�*
* If the Altitude/Distance unit is set to "m," select 3, 6, 12,
24, 49, 98, 195, 390, 780, or 1561 meters�
Gain
[MENU] > GPS > GPS TX Mode > D-PRS >
TX Format > Item > Gain
Selects the gain of the Item's antenna to transmit
along with the position data�
L This item is displayed when "Data Extension" is set to
"Power/Height/Gain/Directivity�"
• Select between 0 and 9 dB�
Directivity
[MENU] > GPS > GPS TX Mode > D-PRS >
TX Format > Item > Directivity
Selects the direction the Item's antenna was pointing
to transmit along with the position data�
L This item is displayed when "Data Extension" is set to
"Power/Height/Gain/Directivity�"
• Select Omni, 45° NE, 90° E, 135° SE, 180°S, 225°
SW, 270° W, 315° NW, or 360° N�
SSID
(Default: 0W)
Selects an SSID based on APRS
sign, to show your operating style to other stations�
L The SSID's additional methods differ, depending on
L See page 6-32 for details of the SSID�
• ---:
(Default: 10ft)
• (-0):
• -1 ~ -15:
• -A ~ -Z:
(Default: 0dB)
(Default: Omni)
6-37
[MENU] > GPS > GPS TX Mode > D-PRS >
TX Format > Item > SSID
whether the call sign includes a space or not�
The space in call sign is converted to "-�"
No SSID is added�
Adds an SSID of -1 to -15 to your call
sign�
Adds an SSID of -A to -Z to your call
sign�
(Default: ---)
to add to your call
®
