8
RECORDER FUNCTION
Playing back the recorded audio on the PC
You can play back the recorded audio on your PC�
L Operation data is not displayed�
L Windows 11 is used for these instructions�
Example: Playing back the audio file on the microSD
card on your PC�
[MENU] > SET > Function > USB Connect
1� Connect the transceiver and PC with a USB cable�
Transceiver
To the
[USB] port
Supplied USB cable
(Type-C/Type-A)
2� Push [MENU]�
3� Select "Function" in the "SET" menu�
4� Select "USB Connect�"
5� Select "SD Card Mode�"
• A confirmation dialog is displayed
6� Select "YES�"
• The transceiver is connected to the PC in the SD
Card mode, and the SD card folder is displayed on
the PC screen�
• The microSD card are directly accessed from the PC�
7� Double-click the 'ID-52' folder�
8� Double-click the 'Voice' folder�
PC
To the
USB port
Double-Click
Double-Click
9� Double-click the folder that contains the audio file
to play it back� (Example: "20240605")
10� Double-click the file to play it back�
(Example: "20240605_120122B�wav")
L See the instruction manual of your player for
operation details�
L The audio file may not play back, depending on the
player�
8-14
Double-Click
Double-Click
