Daf Output; Dheadset Function Select - Icom ID-52A PLUS Advanced Manual

13
Bluetooth ® OPERATION
Headset Settings
These are settings when using a Bluetooth headset�
1� Push [MENU]�
2� Select "Bluetooth Set" in the "SET" menu�
3� Select "Headset Set�"

DAF Output

[MENU] > SET > Bluetooth Set > Headset Set >
AF Output
You can select the AF Output device�
If "AF Output" is set to "Headset & Speaker," you can
hear audio from both a connected Bluetooth headset
and the transceiver's speaker�
L See page 12-32 for details�
TIP: When "AF Output" is set to "Headset Only,"
the following dialog is displayed if the Bluetooth
connection is accidentally disconnected�
• YES: The audio is output from the transceiver's
speaker�
• NO: The transceiver's volume level is automatically
set to 0, and the audio is not output from the
transceiver's speaker�

DHeadset Function Select

You can select the PTT and microphone combination
when either a Bluetooth headset or the transceiver
microphone are used�
L See page 12-32 for details�
[MENU] > SET > Bluetooth Set > Headset Set >
Headset Function Select
• Normal:
Transmitting the voice from the Bluetooth headset
while pressing [PTT] or the internal microphone's
voice�
• Microphone:
Using the Bluetooth headset as a microphone�
L The audio from the internal microphone cannot be
transmitted�
L You can also transmit by pressing the Bluetooth
headset's [PTT]�
• PTT:
Using the Bluetooth headset as a PTT switch�
L The audio from the internal microphone is transmitted�
The audio from the Bluetooth headset cannot be
transmitted�
L You can also transmit by pressing the transceiver's
[PTT]�
The operation of the Bluetooth headset for each
setting is shown in the table below�
Setting Transmit operation
Normal
Microphone
PTT
13-4
Audio input
✔ ✔
✔ ✔
(Use internal microphone)
✔
