Icom ID-52A PLUS Advanced Manual page 183

12
SET MODE
NOTE: The default settings shown below are for the USA transceiver version� The default settings may differ,
depending on your transceiver version�
DUP/TONE...
Offset Freq
[MENU] > SET > DUP/TONE��� > Offset Freq
Sets the frequency offset for Duplex (repeater)
operation to between 0�000�00 and 59�995�00 MHz�
L Push [VFO/MHz] to select the 1 MHz tuning step�
L The Duplex shift direction (DUP–/DUP+) (p� 11-4) or the
tuning step is set in the Quick Menu window�
L When the DR function is ON, editing is disabled�
* The default value may differ, depending on the frequency
band (selected as the MAIN band before entering the
MENU screen) and the transceiver version�
Repeater Tone
[MENU] > SET > DUP/TONE��� > Repeater Tone
Selects a repeater tone frequency for repeater access
and other functions�
You can select 50 tone frequencies (67�0 ~ 254�1 Hz)�
TSQL Freq
[MENU] > SET > DUP/TONE��� > TSQL Freq
Selects a CTCSS tone frequency for the Tone Squelch
function�
You can select 50 tone frequencies (67�0 ~ 254�1 Hz)�
• Selectable Repeater Tone/TSQL frequencies
(Unit: Hz)
67�0 88�5 114�8
69�3 91�5 118�8
71�9 94�8 123�0
74�4 97�4 127�3
77�0 100�0 131�8
79�7 103�5 136�5
82�5 107�2 141�3
85�4 110�9 146�2
Tone Burst
[MENU] > SET > DUP/TONE��� > Tone Burst
Turns the Tone Burst function ON or OFF in the FM
mode when using the Tone Squelch function�
• OFF: When you transmit a signal that superimposes
the CTCSS tone, the other station may hear
a short burst of noise from their receiver, just
after you stop transmitting�
• ON: When you transmit a signal that superimposes
the CTCSS tone, the function mutes the noise
from being heard in the other station's receiver�
(Default: 0�600�00*)
(Default: 88�5)
(Default: 88�5)
151�4 177�3 203�5
156�7 179�9 206�5
159�8 183�5 210�7
162�2 186�2 218�1
165�5 189�9 225�7
167�9 192�8 229�1
171�3 196�6 233�6
173�8 199�5 241�8
(Default: OFF)
DTCS Code
[MENU] > SET > DUP/TONE��� > DTCS Code
Selects a DTCS (both encoder/decoder) code for the
DTCS Squelch�
You can select a total of 104 codes (023 ~ 754)�
• Selectable DTCS codes
023 072
025 073
026 074
031 114
032 115
036 116
043 122
047 125
051 131
053 132
054 134
065 143
071 145
DTCS Polarity
[MENU] > SET > DUP/TONE��� > DTCS Polarity
Selects the DTCS polarity to use for transmitting (TX)
and receiving (RX)�
• Both N: Normal polarity is used for both TX and RX�
• TN-RR: Normal polarity is used for TX, Reverse
• TR-RN: Reverse polarity is used for TX, Normal
250�3
254�1 • Both R: Reverse polarity is used for both TX and
Digital Code
[MENU] > SET > DUP/TONE��� > Digital Code
Selects the digital code for Digital Code Squelch�
You can select a total of 100 codes (00 ~ 99)�
12-4
152 244 311
155 245 315
156 246 325
162 251 331
165 252 332
172 255 343
174 261 346
205 263 351
212 265 356
223 266 364
225 271 365
226 274 371
243 306 411
polarity for RX�
polarity for RX�
RX�
(Default: 023)
412 466 631
413 503 632
423 506 654
431 516 662
432 523 664
445 526 703
446 532 712
452 546 723
454 565 731
455 606 732
462 612 734
464 624 743
465 627 754
(Default: Both N)
(Default: 00)
