Icom ID-52A PLUS Advanced Manual page 200

12
SET MODE
Function
Key Lock
[MENU] > SET > Function > Key Lock
Selects the key lock type when the Key Lock function
is ON�
NOTE: Regardless of the setting, you can still use
[ ], [PTT], and [ ] even if the Key Lock function is
ON�
• Normal: All keys and dials, except [SQL] and [VOL]
are locked�
• No SQL: All keys and dials, except [SQL] are locked�
• No VOL: All keys and dials, except [VOL] are locked�
• ALL: All keys and dials are locked�
PTT Lock
[MENU] > SET > Function > PTT Lock
Turns the PTT Lock function ON or OFF�
To prevent accidental transmissions, this function
inhibits all transmissions�
• OFF: Turns OFF the function�
• ON: Inhibits all transmissions�
Busy Lockout
[MENU] > SET > Function > Busy Lockout
Turns the Busy Lockout function ON or OFF�
This function inhibits a transmission while receiving a
signal, or when the squelch is open�
• OFF: Turns OFF the function�
• ON: Turns ON the function�
Time-Out Timer
[MENU] > SET > Function > Time-Out Timer
To prevent an accidental prolonged transmission,
the transceiver has the Time-Out Timer function� The
function inhibits continuous transmissions longer than
this set period of time�
• OFF: Turns OFF the function�
• 1 to 30 min: The transmission is cut OFF after the
set period of time ends
(1, 3, 5, 10, 15, or 30 minutes)�
(Default: Normal)
(Default: OFF)
(Default: OFF)
(Default: 5min)
12-21
Active Band
[MENU] > SET > Function > Active Band
Selects whether or not to enable continuous frequency
selection of the operating frequency across all bands
using [DIAL]�
• Single: When you rotate [DIAL] on the band edge,
the displayed band's higher or lower
frequency is selected�
• All: When you rotate [DIAL] on the band edge,
the next band is selected�
The selectable frequencies are set to all
bands, for continuous selection�
• HAM: When you rotate [DIAL] on the band
edge, the amateur band's higher or lower
frequency is selected� You cannot select a
frequency out of the amateur band�
L To select another band when "Single" is selected, push
[QUICK], then select "Band Select�"
L This setting is for the [DIAL] operation, so all frequencies
are scanned�
MIC Gain (Internal)
[MENU] > SET > Function > MIC Gain (Internal)
Sets the internal microphone gain to between 1
(minimum) and 4 (maximum), to suit your operation
needs�
Higher values make the microphone more sensitive to
your voice�
MIC Gain (External)
[MENU] > SET > Function > MIC Gain (External)
Sets the external microphone gain to between 1
(minimum) and 4 (maximum), to suit your operation
needs�
Higher values make the microphone more sensitive to
your voice�
(Default: All)
(Default: 2)
(Default: 2)
