Icom ID-52A PLUS Advanced Manual page 116

6
GPS OPERATION (ADVANCED)
GPS items
GPS Out (USB Port)
[MENU] > GPS > GPS Set > GPS Out (USB Port)
Selects whether or not to output the position
information to the USB port�
• OFF: Does not send the position information to
the USB port�
• ON: Send the position information to the USB
port�
GPS TX Mode
[MENU] > GPS > GPS TX Mode
Selects a GPS transmission mode to send GPS
position data while in the DV mode�
• OFF: Does not transmit GPS data�
• D-PRS: Transmits GPS data in the D-PRS format�
• NMEA: Transmits GPS data in the NMEA format�
Unproto Address
[MENU] > GPS > GPS TX Mode > D-PRS >
Unproto Address
Displays an unproto address of up to 56 alphanumeric
characters�
NOTE: You should use the default address, and
editing is not recommended�
(Default: OFF)
(Default: OFF)
(Default: API52,DSTAR*)
Symbol
[MENU] > GPS > GPS TX Mode > D-PRS >
TX Format > Position > Symbol
Selects the symbol that indicates your operating
situation� The selected symbol channel's symbols (1 ~
4) are transmitted with position data�
< Editing a symbol with a 2 character symbol code>
1� Select a symbol channel�
L DO NOT push [ENT]�
2� Push [QUICK]�
3� Select "Edit Symbol�"
4� Push [QUICK]�
5� Select "Direct Input�"
6� Rotate [DIAL] to edit the first digit�
7� Push D-pad() to select the second digit�
8� Rotate [DIAL] to edit the second digit�
Selectable characters and symbols
<For the first digit> /, \, 0 to 9, A to Z
<For the second digit> A to Z, a to z, 0 to 9, ! " #
$ % & ' ( ) * + , - � / : ; < = > ? @ [ \ ] ^ _ ` { | } ˜
9� After editing, push [ENT]�
• Sets the symbol into the symbol channel selected in
step 1�
< Selecting a preset symbol>
1� Select a symbol channel�
L DO NOT push [ENT]�
2� Push [QUICK]�
3� Select "Edit Symbol�"
4� Select a symbol�
• Sets the symbol into the symbol channel selected in
step 1�
6-31
(Default: Person)
