Using The Dtmf Memory; Dentering Dtmf Code; Dmonitoring The Entered Dtmf Code - Icom ID-52A PLUS Advanced Manual

15
OTHER FUNCTIONS

Using the DTMF memory

The transceiver can save up to 16 memories of a 24
digit DTMF code�

DEntering DTMF code

[MENU] > SET > DTMF/T-CALL > DTMF Memory
1� Push [MENU]�
2� Select "DTMF/T-CALL" in the "SET" menu�
3� Select "DTMF Memory�"
4� Select a DTMF Memory to enter�
L DO NOT push [ENT]�
5� Push [QUICK]�
6� Select "Edit�"
7� Enter a DTMF code, then push [ENT]�
(Example: 123456A)
• Saves the Memory, and returns to the DTMF
MEMORY screen�
L See page iii on how to enter characters�
L To exit the MENU screen, push [MENU]�
TIP: To clear the entered DTMF code, push [QUICK]
on the DTMF MEMORY screen, then select "Clear�"

DMonitoring the entered DTMF code

You can check and hear the entered DTMF code�
[MENU] > SET > DTMF/T-CALL > DTMF Memory
1� Push [MENU]�
2� Select "DTMF/T-CALL" in the "SET" menu�
3� Select "DTMF Memory�"
4� Select a DTMF Memory to monitor�
L DO NOT push [ENT]�
5� Push [SQL]�
• The DTMF code sounds�
• After sounding, returns to the DTMF MEMORY
screen�
L To exit the MENU screen, push [MENU]�
TIP: You can also check the DTMF code by pushing
[QUICK] and select "DTMF Monitor" on the DTMF
MEMORY screen in step 4�
15-5
