Snmp Overview - ADC FlexWave Prism System Reference Manual

12.2 SNMP O
The FlexWave system SNMP interface, shown schematically in
remote user using an SNMP manager to access the same database as accessed by the
standard EMS interface. The database accessed is an SNMP database called a
Management Information Base (MIB).
This section describes the FlexWave system SNMP interface, and provides procedures
for using the SNMP interface to "get" and "set" system parameters and receive alarms.
In SNMP terminology, the parameters in a MIB are called "objects" and alarms are
called "traps."
FlexWave Prism Host, Remote and EMS 5.1 System Reference
ADCP-77-073 • Issue 2 • 11/2009
VERVIEW
IP
Web
Windows 2000 or Windows XP
IP
TRAP GET/SET
Network port
EMS
INTERNAL
MIB
URH Host Unit
75356-05
Figure 12-2. SNMP Interface
Figure
computer running
Internet Explorer 6.0
and/or SNMP Manager
© 2009 ADC Telecommunications, Inc.
CORNING EX1005, page 291

SNMP Overview

12-2, allows a
