As shown in Figure
signals are converted to optical signals for distribution to the local coverage area. The
EMS is thus in a position to monitor both types of signals, and to report status,
alarms, and RF signal levels through automatic, periodic updates and in response to
user requests. User requests can include commands to set RF gain and propagation
delay.
BTSs
FlexWave Prism Host, Remote and EMS 5.1 System Reference
ADCP-77-073 • Issue 2 • 11/2009
5-2, you access the embedded EMS through the Host, where RF
Status
User
Alarms
Requests
RF Signal Levels
RF
OPTICAL
HOST
with
Embedded
WDM
Element
(Optional)
Management
System
Figure 5-2. The Function of the EMS
FlexWave EMS Overview
RF
FlexWave
Antennas
REMOTE
77073-021
