ADC FlexWave Prism System Reference Manual page 23

Basic System Components
Tri-Band
Remote Unit
Host Unit
Antenna
Band A
Antenna
Band B
77073-004
Antenna
Band C
RF
RF
RF
Band A
Band B
Band C
Base
Transceiver
Stations
Figure 1-3. Three Bands to One Remote
