SNMP Interface

12.5.3.2 Variable Bindings

For Host Traps, there are 9 variable bindings:
1 1 sysUpTime
2 2 snmpTrapOID
3 3 fwuTrapSequenceNumber
4 4 fwuTrapTimeStamp
5 5 fwuModuleNumber
6 6 fwuModuleType
7 7 fwuHstNumber
8 8 fwuHstName
9 9 fwuNotificationStatus
For Remote Traps, there are 11 variable bindings:
1 1 sysUpTime
2 2 snmpTrapOID
3 3 fwuTrapSequenceNumber
4 4 fwuTrapTimeStamp
5 5 fwuModuleNumber
6 6 fwuModuleType
7 7 fwuHstNumber
8 8 fwuHstName
9 9 fwuRmtNumber
10 0 fwuRmtName
11 1 fwuNotificationStatus
You can therefore determine the affected module based on the module number and
type (variable binding 5 and 6).
