ADC FlexWave Prism System Reference Manual page 324

SNMP Interface
Table 12-3. FlexWave-URH Agent MIB Traps (Cont.)
Trap Object
fwuRmtDARTOverTempFault
fwuRmtDARTUnderTempFault
fwuRmtGPSFault
fwuRmtLPADisableFault
fwuRmtLPAOverPowerFault
fwuRmtLPAHighTempFault
fwuRmtLPAVswrFault
fwuRmtLPADcFault
fwuRmtLPALoopFault
fwuRmtLPALowPowerFault
fwuRmtLPADetectFault
fwuRmtSystemVswrFault
fwuRmtNoRFPowerFault
fwuRmtLNAPowerFault
fwuRmtFanFault
fwuRmtACPowerSupplyMon4Fault
fwuRmtACPowerSupplyMon1Fault
fwuRmtACPowerSupplyMon2Fault
fwuRmtACPowerSupplyMon3Fault
fwuHstSysCardPrimaryCPFault
fwuHstSysCardSecondaryCPFault
Page 310
© 2009 ADC Telecommunications, Inc
Description
indicates a Remote DART Card Over Temperature Fault
Indicate the Remote DART Card Under Temperature Fault
Remote GPS fault
Disable state of the linear power amplifier
Internal over power fault state of linear power amplifier
(power level is high enough to damage LPA)
Remote LPA High Temperature fault
Internal VSWR fault state of linear power amplifier
(greater than 3:1)
Remote LPA DC fault
Remote LPA Loop fault
Internal low power fault state of linear power amplifier
(the gain of one or more internal amplifiers does not
meet specification)
Presence fault state of linear power amplifier (the LPA is
missing)
Remote system Vswr fault
Remote No RF Power fault
Remote LNA power fault
Remote system VSWR fault. This object hasn't been
implemented in this release
AC Power monitor 4 Fault
AC Power monitor 1 Fault
AC Power monitor 2 Fault
AC Power monitor 3 Fault
Primary Clock Priority Fault
Secondary Clock Priority Fault
FlexWave Prism Host, Remote and EMS 5.1 System Reference
ADCP-77-073 • Issue 2 • 11/2009
