FlexWave Element Management System
5.1 F W
LEX
The ADC FlexWave EMS is an embedded software application that is accessed through
an internet connection using a Web browser and provides a Graphical User Interface
(GUI) for control and monitoring of a Prism system.
Figure 5-1. Typical FlexWave Prism System
Page 136
© 2009 ADC Telecommunications, Inc
EMS O
AVE VERVIEW
IP
WEB
Windows 2000 or Windows XP
IP
EMS
HOST
FlexWave Prism Host, Remote and EMS 5.1 System Reference
computer running
Internet Explorer 6.0
REMOTE
UP TO 8
REMOTE
77073-020
ADCP-77-073 • Issue 2 • 11/2009
