Installing the Remote Unit
4.4.10

Mount the Remote and Power Up

52 2 Refer to the detailed instructions for mounting the FlexWave Prism Remote in the
Remote Unit Mounting Kit Installation Instructions (ADCP-77-077) to mount the
Remote in the location selected in
96.
53 3 Power up the Remote by turning its AC power switch to On.
SeRF
Module
AC Power
switch for
Remote
chassis
54 4 Close and tightly secure the Remote door and Solar Shield.
Page 132
© 2009 ADC Telecommunications, Inc
Section 4.2, Remote Mounting Plans, on page
77073-049
FlexWave Prism Host, Remote and EMS 5.1 System Reference
ADCP-77-073 • Issue 2 • 11/2009
