Installing the Remote Unit
48 8 Enter the power consumption in the spaces provided below.
49 9 For the total RF Module power consumption, calculate the power consumption
from Table 4-3 on page 131
A - D), add the Watts, and then enter the total in the Total Power Consumption
field.
SeRF Module power consumption from
Additional SFPs _____ x 1.25W
RF Module A power consumption from
RF Module B power consumption from
RF Module C power consumption from
RF Module D power consumption from
50 0 Divide the total Watts by the input Voltage to determine the current (Amperes)
requirements.
51 1 Determine the circuit breaker or fuse size based on local codes and practices.
Circuit breaker or fuse size must be 20 Amps or less.
Page 130
© 2009 ADC Telecommunications, Inc
for each RF Module present in the Remote (RF Module
Table 4-2
Table 4-3
Table 4-3
Table 4-3
Table 4-3
TOTAL POWER CONSUMPTION
Watts
= Amps
Volts
FlexWave Prism Host, Remote and EMS 5.1 System Reference
_________Watts
_________Watts
_________Watts
_________Watts
_________Watts
_________Watts
_________Watts
