FlexWave Prism System
1.1 P
RISM
ADC's FlexWave™ Prism is a compact radio head for macro gap coverage that
supports up to four frequency bands delivering high-performance coverage with
end-to-end management.
The FlexWave Prism enhances wireless networks in outdoor locations and large
venues in an easy and cost-effective manner. Based on patented technology and
ADC's 15-year leadership in outdoor wireless distributed antenna system (DAS)
technology, FlexWave Prism offers mobile operators a small, light, and flexible
solution for extending macro network coverage for 2G, 3G, and 4G services.
The new FlexWave Prism system is ideal for enhancing outdoor and indoor coverage
in cities, suburbs, canyons, tunnels, campuses, stadiums, and other public areas. It is
35 percent lighter and up to 60 percent smaller than the FlexWave URH product it
replaces, and is available in four different cabinet sizes to support one, two, three or
four frequency bands. Operators can future-proof their deployments by purchasing
a larger cabinet and adding more frequency bands when needed. FlexWave Prism uses
ADC's proven radio head technology and management system along with an IP-65
rated remote.
1.1.1

Product Features

• • Management under the same host end equipment and EMS as the FlexWave URH,
allowing operators to scale legacy URH deployments with the FlexWave Prism
• • ADC's patented RF-over-fiber transport eliminates installation-dependent gain or
fiber length adjustments
• • Improved manageability for installation and upgrades
• • Smaller size to ease placement and zoning approvals
• • 4G readiness with Four Band remote, which is ideal for incorporating 2G and 3G
services with needs of 4G technologies such as LTE
• • The unique capability to support digital RF as well as baseband compatibility into
a single fiber pair and remote radiating point
• • Support for millimeter wave backhaul
• • With its unique use of wideband digital RF transport, FlexWave Prism delivers
reliable and consistent performance in all environments. Signals are not affected
by reflection, dispersion, or frequency attenuation over fiber. FlexWave Prism
delivers a reliable signal at every remote location.
