ADC FlexWave Prism System Reference Manual page 327

A
H
OST
Content
A.1 Host Fan Replacement Procedure .......................................................................314
A.2 Power Supply Replacement Procedure ................................................................315
A.3 System Card Replacement Procedure ..................................................................317
A.4 SeRF Card Replacement Procedure .....................................................................319
A.4.1 Preserve System Configuration...................................................................319
A.4.2 Remove the SeRF Card..............................................................................322
A.4.3 Swap Compact Flash From Old SeRF Card to New SeRF Card..........................323
A.4.4 Install New SeRF Card...............................................................................324
A.5 DART Card Replacement/Installation Procedure ....................................................325
A.5.1 Replacing a DART Card in the Host Chassis ..................................................325
A.5.2 Installing a New DART Card in the Host Chassis ............................................325
This section provides the Host maintenance procedures. Refer to this section when
scheduled maintenance is required.
Recommendation: : The replacement interval for the Host fan is 60 months.
FlexWave Prism Host, Remote and EMS 5.1 System Reference
ADCP-77-073 • Issue 2 • 11/2009
U M
NIT ODULE
R
EPLACEMENT
©2009 ADC Telecommunications, Inc.
CORNING EX1005, page 327
