4. Instruction Execution Times and Number of Steps
Instruction Mnemonic
ARITHMETIC SHIFT ASR
RIGHT
DOUBLE SHIFT ASRL
RIGHT
ROTATE LEFT ROL
DOUBLE ROTATE ROLL
LEFT
ROTATE LEFT WITH- RLNC
OUT CARRY
DOUBLE ROTATE RLNL
LEFT WITHOUT
CARRY
ROTATE RIGHT ROR
DOUBLE ROTATE RORL
RIGHT
ROTATE RIGHT RRNC
WITHOUT CARRY
DOUBLE ROTATE RRNL
RIGHT WITHOUT
CARRY
ONE DIGIT SHIFT SLD
LEFT
ONE DIGIT SHIFT SRD
RIGHT
SHIFT N-BIT DATA NSFL
LEFT
SHIFT N-BIT DATA NSFR
RIGHT
SHIFT N-BITS LEFT NASL
DOUBLE SHIFT N- NSLL
BITS LEFT
SHIFT N-BITS NASR
RIGHT
DOUBLE SHIFT N- NSRL
BITS RIGHT
4-3-8 Increment/Decrement Instructions
Instruction Mnemonic
INCREMENT ++
BINARY
DOUBLE INCRE- ++L
MENT BINARY
DECREMENT – –
BINARY
DOUBLE DECRE- – –L
MENT BINARY
INCREMENT BCD ++B
DOUBLE INCRE- ++BL
MENT BCD
1206
Length
(steps)
CS1H
CPU6@H
2 0.22
2 0.40
2 0.22
2 0.40
2 0.22
2 0.40
2 0.22
2 0.40
2 0.22
2 0.40
3 5.9
561.1
3 6.9
760.5
4 7.5
40.3
4 7.5
50.5
3 0.22
3 0.40
3 0.22
3 0.40
*1 The instruction execution time is greatly affected by the amount to data. This will
affect the cycle time. To reduce the effect on the cycle time, background execu-
tion can be specified.
Length
(steps)
CS1H
CPU6@H
2 0.22
2 0.40
2 0.22
2 0.40
2 6.4
2 5.6
ON execution time ( s)
CS1G CS1H CS1G
CPU4@H CPU6@ CPU4@
0.32 0.29 0.37
0.56 0.50 0.67
0.32 0.29 0.37
0.56 0.50 0.67
0.32 0.29 0.37
0.56 0.50 0.67
0.32 0.29 0.37
0.56 0.50 0.67
0.32 0.29 0.37
0.56 0.50 0.67
6.1 8.2 8.2
626.3 760.7 760.7
7.1 8.7 8.7
895.5 1070 1070
8.3 10.5 10.5
45.4 55.5 55.5
8.3 10.5 10.5
55.3 69.3 69.3
0.32 0.29 0.37
0.56 0.50 0.67
0.32 0.29 0.37
0.56 0.50 0.67
ON execution time ( s)
CS1G CS1H
CPU4@H CPU6@
0.32 0.29 0.37
0.56 0.50 0.67
0.32 0.29 0.37
0.56 0.50 0.67
4.5 7.4 7.4
4.9 6.1 6.1
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Conditions
---
---
---
---
---
---
---
---
---
---
Shifting 1 word
Shifting 1,000 words
Shifting 1 word
Shifting 1,000 words
Shifting 1 bit
Shifting 1,000 bits
Shifting 1 bit
Shifting 1,000 bits
---
---
---
---
Conditions
CS1G
CPU4@
---
---
---
---
---
---
